Our new  range of architectural retractable roof systems are suitable for use in nearly all weather conditions for residential and commercial applications.

We have a model to suit for your home to provide unprecedented outdoor living flexibility.

For commercial customers we can provide you with a custom made retractable roof system for your restaurant, bar or cafe.

Using the latest European design and technology our new range of retractable roofs will give you a new meaning of alfresco dining.

Being able to enjoy beautiful blue sky during the day or the stars on a clear night with the flexibility of quickly closing your roof with a remote control if the weather starts to change.

Call us now for one of our expert staff to do a site visit and provide you with a quotation for your own retractable roof system.

Three Stunning Ranges:

• Design Series HS12 – with posts, up to 6m extension
• Design Series HS12 – with posts, up to 10m extension
• Trend Series – attaches to existing structure, up to 10m extension

Sizes – All units maximum 4.5m wide in a single unit, and 9m wide in a twin unit. Separate units can be mounted side by side with very little gap to cover unlimited areas.

Lighting – LED down lights can be built into fabric bars. Generally spaced on every third bar, and 800mm apart. Adds approx $2500-3000 to job. As they are made to order, can be spaced anywhere you desire.

Fabric – Waterproof PVC, including Ferrari 502 13% translucent, Ferrari 702 block out, Sundream approx 40% translucent.

Powder coating – System pricing allows for two powder coating colours – Framework, any of 120 standard powder coating colours . Fabric bars either standard white (slightly cheaper) or any of 120 standard powder coating colours.

Fabric bars – Fabric bars are generally spaced 450-500mm apart, and when retracted the fabric hangs down 300mm. When retracted each fabric bar takes up 65mm, and a powder coated hood sheet is installed to cover the retracted unit to protect from the weather and block any gap between the unit and the wall.

Control – Remote motor

Warranty – 5 years

Wind rated – Beaufort wind scale up to category 11

Mounting – Wall brackets, or side brackets on rafters (if installed in a courtyard), runoff setting 4 to 10 degree angle depending on size of unit. The unit can be mounted with a side fall.

Installation – Each unit takes approximately 8-10 hours to install for a 2 person team.

Delivery – Please allow 6-8 weeks for delivery and installation from receipt of deposit.

Drop screens – Horizontal beams can be added on either side of the unit to mount drop curtains, and infill panels can be fitted between the horizontal beam and the rafter. Infill panels will be permanently fitted using spline tape/rope track and can be from Clearglass PVC, mesh PVC or solid PVC fabric.

We have the following drawing files available for the All Seasons range. Please contact awnings@coolawnings.co.nz if your require any of these drawings.

GSM – archiCAD files
DWG – very readily used format in a range of softwares (eg Autocad)
DXF – very readily used format in a range of softwares (eg Autocad)
RFA – Revit (3D drawing works)
AMX – high detail used for rendering
3DS – high detailed like max but slightly smaller file size, used for animation
